Product Description
DeanLine Series Chemical Process Industrial Inline Pumps
Introducing the DeanLine .75x.75 (Class 50: Stainless Steel) inline pump, engineered for reliable performance in chemical process applications.
Product Highlights:
- Efficient Design: The DeanLine Series offers inline pump convenience, simplifying installations without the need for a separate coupling.
- High-Performance: Powered by a 1hp motor running at 3500rpm, with a 4-1/4" impeller for optimal flow and equipped with an explosion-proof motor for hazardous environments.
- Durability & Versatility: Available in cast iron and 316SS construction, this pump is factory tested for operating performance and casting soundness, ensuring reliability in demanding environments.
- Temperature & Pressure Capabilities: Handles pumping temperatures up to 220°F (104°C) and working pressures up to 100 PSIG (689 kPa).
- Sealing Solutions: Multiple mechanical seal options are available depending on your specific application, including the standard John Crane 9A Mechanical Seal for enhanced leakage prevention.
Applications:
Designed for a variety of process plant applications, including but not limited to:
- Transfer Services
- Condensate Service
- Tank Car Unloading
- Heat Transfer Liquids
- Water Circulation (Aquarium, Hospital, Lime, Soft Slurries)
Commonly Handled Liquids Include:
- Acetic Acid & Water
- Alcohol & Water
- Hydrocarbons
- Heat Transfer Oil
- Glycol, Methanol, Xylene, and more.
Important Notes:
- Shipping: Product is territory restricted and not eligible for free freight.
For proper sizing and selection, utilize the Dean Selection Tool or contact us directly for personalized assistance. Be sure to check out the DeanLine Bulletin, DataPak, and IOM for additional technical resources.
