Product Description
Dean RWA4206 4x6x10 #1 Shaft Repair Kit
Genuine Dean shaft repair kit for the RWA4206 4x6x10 #1 only. Use this kit to rebuild the rotating element—shaft, mechanical seal, bearings, grease seals, gaskets, and related hardware—so the pump returns to reliable service.
NOTE: This repair kit is only for a Dean RWA4206 4x6x10 #1 pump. Do not use on #2 or other frames.
This kit includes:
| Item No. | Part Number | Description | Qty |
|---|---|---|---|
| 10 | 1768334 | SHAFT SLEEVE | 1 |
| 10A | 9053524 | SET SCREW | 4 |
| 13 | 1762483 | MECHANICAL SEAL GLAND | 1 |
| 21 | 9053532 | SET SCREW | 4 |
| 25A | 9010202 | THRUST BEARING | 2 |
| 26B | 9454036 | 1/2 PIPE PLUG | 1 |
| 29 | 1138163 | PUMP SHAFT | 1 |
| 31 | 9212521 | BEARING LOCKNUT | 1 |
| 31A | 9656521 | BEARING LOCK WASHER | 1 |
| 76 | 9603039 | GREASE SEAL FRONT | 1 |
| 76A | 9603034 | GREASE SEAL REAR | 1 |
| 77 | 9156096 | CASING GASKET | 1 |
| 77B | 9710686 | BEARING END COVER GASKET | 1 |
| 77C | 9710690 | SHAFT SLEEVE O-RING | 1 |
| 95A | 6765948 | MECHANICAL SEAL STATIONARY | 1 |
| 95B | 6765948 | MECHANICAL SEAL ROTARY | 1 |
| 180 | 6010113 | RADIAL BEARING CARTRIDGE | 1 |
| 325 | 9710689 | O-RING | 2 |
| 375 | 9690128 | ANTI ROTATING PIN | 1 |
Part numbers link to the matching PumpResource product page when that SKU is in the store. Need help matching a seal face or verifying fit? Contact us before you order.
Matching pump
For Dean RWA4206 — 4x6x10 #1 only. Do not use on #2 or other frames.
